✨ panel-reactflow

A Panel wrapper for the React Flow JS library.

Features

• Python-first, JSON-serializable graph state
• Panel viewables inside nodes via node view entries
• Interactive editing (drag/select/connect/delete) with sync back to Python
• Optional schema definitions for node/edge properties
• Event callbacks via ReactFlow.on(...) for app-level handling

Pin your version!

This project is in its early stages, so if you find a version that suits your needs, it’s recommended to pin your version, as updates may introduce changes.

Installation

Install it via pip:

pip install panel-reactflow

Usage

import panel as pn

from panel_reactflow import ReactFlow

pn.extension("jsoneditor")

nodes = [
    {
        "id": "n1",
        "position": {"x": 0, "y": 0},
        "type": "panel",
        "label": "Start",
        "data": {},
        "view": pn.pane.Markdown("Node 1 content"),
    },
    {
        "id": "n2",
        "position": {"x": 260, "y": 60},
        "type": "panel",
        "label": "End",
        "data": {},
        "view": pn.pane.Markdown("Node 2 content"),
    },
]
edges = [
    {"id": "e1", "source": "n1", "target": "n2"},
]

flow = ReactFlow(
    nodes=nodes,
    edges=edges,
)

flow

For property schemas and richer editors, provide node_types/edge_types with PropertySpec and handle changes via ReactFlow.on(...).

Development

git clone https://github.com/panel-extensions/panel-reactflow
cd panel-reactflow

For a simple setup use uv:

uv venv
source .venv/bin/activate # on linux. Similar commands for windows and osx
uv pip install -e .[dev]
pre-commit run install
pytest tests

For the full Github Actions setup use pixi:

pixi run pre-commit-install
pixi run postinstall
pixi run test

This repository is based on copier-template-panel-extension (you can create your own Panel extension with it)!

To update to the latest template version run:

pixi exec --spec copier --spec ruamel.yaml -- copier update --defaults --trust

Note: copier will show Conflict for files with manual changes during an update. This is normal. As long as there are no merge conflict markers, all patches applied cleanly.

❤️ Contributing

Contributions are welcome! Please follow these steps to contribute:

1. Fork the repository.
2. Create a new branch: git checkout -b feature/YourFeature.
3. Make your changes and commit them: git commit -m 'Add some feature'.
4. Push to the branch: git push origin feature/YourFeature.
5. Open a pull request.

Please ensure your code adheres to the project's coding standards and passes all tests.
